Alamo Machete #3 25' Rotary Boom Mower Attachment

Alamo Machete #3 25' Rotary Boom Mower Attachment

This pricy boom mower system was carefully removed from its tractor in fair to good working condition and sits on (8) skids as shown in the photos. The Pro's at Stephenson Equipment have heavy equipment and will assist the buyer with loading their appropriate size vehicle.

Including:

The boom arm has a 25' reach and is a hydraulic type

The Severe Duty Rotary cutter head is estimated at 60" type, bidders are encouraged to inspect

The hydraulic power unit

Various style counterweights

Heavy mounting frame and heavy bracketing

Also (1) Large sealed crate of additional parts

This pricy system was in fair to good working condition when removed from service, and comes as shown in the photos

Today's new replacement cost is estimated from $50,000 to $65,000

Sold AS IS

Good luck bidding

The following general information is web-sourced and may contain variances from the subject unit:

• Closed-Loop Piston System: Unlike traditional systems that use gear pumps, the Machete 3 utilizes tandem, closed-loop piston pumps and motors. It runs significantly cooler, delivers more fluid power, and extends the overall life of the machinery.
• Independent Operation: It features its own reservoir and independent load-sensing piston pump for the control circuits. It operates entirely separate from your tractor's internal hydraulic valves.

• Articulated Range: The boom features a 2-section articulated arm capable of reaching up to 25 feet horizontally, over 25 feet vertically, and deep into embankments roughly 12 feet below grade.
• King Post Turning Arm: The heavy-duty cast turning arm swings hydraulically up to 120 degrees from front to back using a 2.5-inch chrome steel king pin.
• Industrial Durability: Built completely out of heavy-duty alloy steel structural tubing, the main pivot points are reinforced and use massive 2-inch pins surrounded by greaseable, hardened steel bushings.
• Transport Safety: When moving between job sites, a specialized two-piece boom rest cradles and secures the arm directly to the tractor framework.

• Cutting Capacity: The high-torque rotary blades can aggressively mulch through grass, weeds, and thick woody material up to 5 inches in diameter.
• 215-Degree Head Rotation: An improved four-bar linkage allows the cutting head to tilt up to 215 degrees. This permits precision cutting around culverts, behind guardrails, or perfectly vertical fence-line trimming.
• Quick Hitch Compatibility: The assembly supports Alamo's proprietary Quick Attach system, allowing operators to swap out the rotary deck for flail heads, ditchers, or buzz saws in roughly 10 minutes.
